Automatic Strap Forming Machine
Co-effort offers a professional and customized Automatic Strap Forming Machine.There are manual/automatic operation modes. It has manual and automatic switching function: under manual state, it can be operated on a single machine for easy maintenance; under automatic state, it can be operated on the whole line and started sequentially; with emergency stop button, it is easy to deal with emergencies and ensure the safety of equipment and operators.Manual operation panel beside the machine is convenient for workers to operate. https://youtu.be/o-0wK3O1pCk Machine Technical Parameters and Description 1. Machine Parameters No Items Technical Requirements 1 Production Process De-coiler and Leveling — Punching and Cutting — Angle Press — Trunnion Loop Forming — Rolling — Discharge 2 Floor Area 10×3.5×3(L×W×H)M 3 Feeding Direction From Left to Right 4 Voltage According to customer requirement 5 Air Supply Flow Rate:0.5m³/min; Pressure: 0-0.7MPa 6 Hydraulic Fluid Anti wear hydraulic oil L-HM46# 7 Gear Oil L-220 8 Material of Strip Stainless Steel 9 Width of Strip ≤60mm 10 Thickness of Strip ≤2.5mm 11 Speed 5~6pcs/min 12 Length Tolerance ±0.1mm 13 Total Power Around 30 KW 14 Tooling change time At least 1 hour 2. Electric Elements Brand No Items Brand Remark 1 PLC HCFA 2 HMI HCFA 3 Electric Elements Schneider 4
